Printed Circuit Board Assembly (PCB Assembly)

We offer a complete line of surface mount, thru-hole, FLEX, and mixed technology printed circuit board assembly. We also offer Box build, electro-mechanical, and complete product integration options. Our Turn-key assembly offers you a simple solution to your requirements, without the need for managing and scheduling materials, while at the same time utilizing our buying power and reliable supply chain. If you prefer to manage your own inventory, we offer a consigned assembly option.



Surface Mount Technology (SMT) Assembly

Surface mount capabilities include:

  • Fine Pitch Devices & Interconnect
  • BGA, QFP, DFN
  • Components from 01005 to 56mmx56mmx15mm.
  • Odd Form
  • High-Density
  • Single & Double Sided
  • Aqueous and No-Clean chemistries
  • Leaded and Lead-Free processes.

Surface Mount Assembly Lines Consist Of:

  • EKRA: X4 & XPRT5 in-line screen printers (with 2 1/2 D paste inspection)
  • MYDATA: MY9E, MY12E, MY200 high-speed placement machines
  • TECHNICAL DEVICES: NU/FLO CV-820 reflow ovens



Surface Mount Process Verification & Inspection

Throughout multiple stages of Surface Mount Assembly, we use AOI, X-ray, and manual inspection for process verification and inspection.



Verification and Inspection Equipment includes:

  • ECD: Super Mole Gold Six-channel Type K Thermal Profiler
  • MIRTEC: MV6 3D Automated Optical Inspection (AOI) Systems
  • GLENBROOK: RTX-113 X-ray Inspection system
  • MANTIS ELITE 3D INSPECTION MICROSCOPE (12)

Thru-hole (THT / PTH) Assembly

Thru-hole capabilities include:

  • Automated & Semi-automated
  • Manual assembly
  • Aqueous and No-Clean chemistries
  • Leaded and Lead-Free processes.



Thru-hole Production Equipment Includes:

  • ACE PRODUCTION TECHNOLOGIES: K.I.S.S. 103 Fully Automated Selective Soldering Systems
  • TECHNICAL DEVICES: NU/ERA 16 Wave Soldering Machines (Lead & Lead Free)
  • Progressive Leaded and Lead-Free Assembly Slide-lines



Thru-hole Process Verification & Inspection

Throughout multiple stages of Thru-hole assembly, we use AOI and manual inspection for process verification and inspection.



Verification and Inspection Equipment includes:

  • ECD: Super Mole Gold Six-channel Type K Thermal Profiler
  • MIRTEC: MV-3L Automated Optical Inspection (AOI) Systems
  • MV6 3D Automated Optical Inspection (AOI) Systems
  • VISION ENGINEERING : MANTIS Dynoscope Inspection Systems (15)
